Enhance your WiFi coverage with Spark Smart Mesh 2


Do you have areas in your home where your WiFi can't reach? A Spark Smart Mesh 2 will help extend and improve your WiFi coverage.

The Spark Smart Mesh 2 connects to your compatible WiFi 6 modem. The modem and Smart Mesh 2 act as a single network that share the same WiFi network name and password. That means there's no need to remember a different login. The Smart Mesh 2 is quick to set up, and will stretch and strengthen your signal so you'll be enjoying WiFi throughout your home within moments.



How to set up your modem and Smart Mesh 2

Before you begin, make sure your modem is set up and connected to the internet.



Things you should know


HARDWARE
BCM6752 - 1.5Ghz Triple core processor
2 x auto-sensing 10/100/1000Mbps Ethernet LAN port
256MB DDR3
128MB DDR3
128MM SPI NAND Flash

SECURITY
Supports latest WPA3 WiFi encryption

WIFI TECHNOLOGY
4x4 WiFi 6 (5Ghz – 802.11 ax) with 1024 QAM support
2x2 WiFi 6 (2.4Ghz - 802.11 ax) with 1024 QAM support

DATA RATE
5Ghz – Supports up with speeds to 4803.5Mbps*
2.4 Ghz – Supports up with speeds to 573.5Mbps*

WIFI ROAMING
WiFi roaming IEEE® 802.11k/v
WiFi band steering

PHYSICAL SPECIFICATIONS
Dimensions: 140*140*55mm

* Maximum wireless signal rate derived from IEEE 802.11 specifications. Actual data throughput and wireless coverage will vary and may be lowered by network and environmental conditions, including network traffic volume and building construction. Spark makes no representations or warranties about this product’s compatibility with future standards.

If your modem is a Spark Smart Modem 2, Spark Smart Modem 3 or Spark 5G Smart Modem you'll only need one Smart Mesh 2 to expand your WiFi coverage. If you need to expand your WiFi coverage further you can connect up to four Smart Mesh 2 units to your network.

Using Spark Smart Mesh 2 with any other modem, you'll need a minimum of two Smart Mesh 2 units to create the network. You can connect up to four. One will remain connected to your modem via an ethernet cable and the others will connect to it via WiFi to expand your WiFi coverage.

Spark Smart Mesh 2 is not compatible with the original Spark Smart Mesh. This means you won't be able to add a Smart Mesh 2 onto a mesh network that already has an original Spark Smart Mesh in it.

See our online user guide to learn how to set up Smart Mesh 2. Set up Smart Mesh 2
